Product Catalog
>
Buzzer
> Mechanical-Buzzer
Check your order list
Product Info ...
Type:
FBMMB2618(A,B,C,D,E,F)
Product Name:
Mechanical Buzzer
Description:
Ø26*17.6mm,
China Mechanical buzzer manufacturer FBMMB2618(A,B,C,D,E,F), FBELE Brand,
Model
FBMMB2618A
FBMMB2618B
FBMMB2618C
FBMMB2618D
FBMMB2618E
FBMMB2618F
Rated Voltage
1.5VDC
3VDC
6VDC
9VDC
12VDC
24VDC
Operating Voltage
1~2VDC
2~4VDC
4~8VDC
6~12VDC
9~15VDC
15~27VDC
Max.Rated Current
40mA/1.5VDC
40mA/3VDC
40mA/6VDC
40mA/9VDC
40mA/12VDC
40mA/24VDC
Min.Sound Pressure Level
85dB/20cm
80dB/20cm
80dB/20cm
80dB/20cm
85dB/20cm
85dB/20cm
Resonant Frequency
400±100Hz
400±100Hz
400±100Hz
400±100Hz
400±100Hz
400±100Hz
Operating Temperature
-20~+60°C
-20~+60°C
-20~+60°C
-20~+60°C
-20~+60°C
-20~+60°C
