| Type: |
FBGTF(1021,1022) |
| Product Name: |
RF1-20(RF2-20) Inner weld ��?5.2??20 Glass Tube Fuse (Quick-acting) |
| Description: |
INTERRUPTING RATING:
35A OR 10In WHICHEVER IS GREATER
3C/VDE/SEMKO |
|
| |
|
|
| Appliance Lamp Holder | FBGTF1021-0100 | FBGTF1021-0125 | FBGTF1021-0150 | FBGTF1021-0160 | FBGTF1021-0200 | FBGTF1021-0250 | FBGTF1021-0300 | FBGTF1021-0315 | FBGTF1021-0350 | FBGTF1021-0400 | | Rated Current | 100mA | 125mA | 150mA | 160mA | 200mA | 250mA | 300mA | 315mA | 350mA | 400mA | | | 3500 | 2100 | 2100 | 2000 | 1700 | 1400 | 1300 | 1300 | 1200 | 1000 | | Appliance Lamp Holder | FBGTF1021-0600 | FBGTF1021-0700 | FBGTF1021-0750 | FBGTF1021-0800 | FBGTF1021-1000 | FBGTF1021-1200 | FBGTF1021-1250 | FBGTF1021-1500 | FBGTF1021-1600 | FBGTF1021-1800 | | Rated Current | 600mA | 700mA | 750mA | 800mA | 1A | 1.2A | 1.25A | 1.5A | 1.6A | 1.8A | | | 650 | 650 | 600 | 240 | 200 | 200 | 200 | 200 | 190 | 190 | | Appliance Lamp Holder | FBGTF1021-2000 | FBGTF1021-2500 | FBGTF1021-3000 | FBGTF1021-3150 | FBGTF1021-3500 | FBGTF1021-4000 | FBGTF1021-5000 | FBGTF1021-6000 | FBGTF1021-6300 | FBGTF1021-7000 | | Rated Current | 2A | 2.5A | 3.0A | 3.15A | 3.5A | 4.0A | 5.0A | 6.0A | 6.3A | 7.0A | | | 170 | 170 | 150 | 150 | 150 | 130 | 130 | 130 | 130 | 120 | | Appliance Lamp Holder | FBGTF1021-8000 | FBGTF1021-10000 | FBGTF1021-12000 | FBGTF1021-15000 | | Rated Current | 8A | 10A | 12A | 15A | | Rated Voltage | 100 | 100 | 100 | 100 | |
| |
|
|
|
|
|
