Model No.	Rated Impedance (Ω±15%)	Rated Power (W)	Max. Power (W)	Resonant Frequency (Hz±20%)	Frequency Range Fo(Hz)	Sound Pressure Level (±3dB)	Operating Temperature (??)	Magnet Size (mm)	Size (mm)
									Diameter	Height
FBS118A	8	5	10	130	12000	89	-20 ~ +55	60X32X10	118X118	48
